CARACTERÍSTICAS
- Impresión a una o dos caras y laminado.
- Laminación directa instantánea de calefacción.
- Velocidad de impresión y laminación: 23 sec./card (YMCK y laminación simple).
- Campo 50S y 50D actualizable a 50L.
- Laminación holográfica para bandas visuales, contacto y contabilidad, SIM.
- LCD de 2 líneas con 2 botones LED para operación frontal.
- Módulos actualizables: Red.
ESPECIFICACIONES
| SMART-50L | |
| Card Printer and Laminator | |
| Printing | |
| Print Type | Dye-Sublimation |
| Print Area | Edge to Edge |
| Resolution | 300dpi |
| Dual Side Printing | Yes(Flipper Installed) |
| Card | |
| Card Feeding | Automatic |
| Card Size | ISO CR80 (54mm x 86mm / 2.12″ x 3.38″) |
| Card Thickness | 0.38mm(15mil) – 1.0mm(40mil) |
| Card Type | PVC, Composite PVC, PET |
| Print Speed | |
| Monochrome | 5 sec./card (720 cards/hour) |
| YMCKO | Max. 18 sec./card (200 cards/hour) |
| YMCKOK | Max. 23 sec./card (155 cards/hour) |
| Laminating | |
| Laminating Mode | Single & Dual Lamination |
| LaminatingFilm | 0.6mil, 1.0mil (Clear&Holographic) |
| Simultaneous 23 sec. (YMCK, Single Lamination) | |
| Simultaneous 33 sec. (YMCKK, Single Lamination) | |
| One by One: 44 sec. (YMCK, Single Lamination) | |
| One by One: 54 sec. (YMCKK, Single Lamination) |
| Capacity | |
| Input Hopper | 100 cards |
| Output Hopper | 40 cards |
| System | |
| Memory | 64MB RAM |
| Display & Control Panel | 2 Lines LCD Display / 2 LED Buttons |
| Supported Platforms | Microsoft Windows 2000/2003/XP/Vista/7/8/10/Mac OS/Linux |
| Comunication | USB, Ethernet (Option) |
| Power Supply | Free Voltage (AC110/220V, 50-60Hz) |
| Power Consumption (Max) | 96W |
| Temperature/Humidity | 15-35ºC / 20-80% |
| Dimensions | |
| Dimensions (WxLxH) | 170mm x 900mm x 195mm |
| Weight | 9.2Kg / 20lbs |
| Encoding Options | |
| Magnetic | ISO 7811 (Track I, II, III Read/Write), / HiCo / LoCo, JIS II |
| Contact Smartcard | ISO 7816 (ID-1) |
| Contactless Smartcard | MIFARE, ISO 14443 (Type A/B) |
| (Internal & External) | ISO 15693, DESFIRE, iCLASS |
| Certifications | CB, CE, FCC, KC, C-tick, UL |


Sensor de Cantidad Residual
Notificaciones de alerta de espacio completo
Indicador LED
Fácilmente el estado del flipper se puede comprobar
Bloqueo físico y sistema de bloqueo Kensington para aumentar la seguridad
Bloqueo físico: Bloqueo Kensington:
Mecanismo de bloqueo Un sistema antirrobo
del cartucho para el módulo
